Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)
Sizes:
3 mm thickness: 202 x 85 x 59 mm (7.95 x 3.35 x 2.32'')
1/8''(3.175mm) thickness: 214 x 90 x 62 mm (8.42 x 3.54 x 2.46'')
4 mm thickness: 269 x 113 x 79 mm (10.60 x 4.46 x 3.10'')
6 mm thickness: 404 x 170 x 118 mm (15.91 x 6.69 x 4.65'')
1/4''(6.35mm) thickness: 428 x 180 x 125 mm (16.83 x 7.08 x 4.92'')
Work area:
3 mm thickness: 491 x 209 mm (19.33 x 8.23'')
1/8''(3.175mm) thickness: 520 x 221 mm (20.46 x 8.71'')
4 mm thickness: 655 x 279 mm (25.77 x 10.97'')
6 mm thickness: 982 x 418 mm (38.66 x 16.46'')
1/4''(6.35mm) thickness: 1039 x 442 mm (40.92 x 17.42'')
In the file:
green color - draw (cut with little power and high speed)
pink color - cut
black color - cut
What you receive:
You will download 1 ZIP file containing the following:
the CDR, DXF, AI, SVG files with drawing for material thinkness 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) and PDF-assembly instruction
If you have any quastions feel free to contact us.
These files are vector-based and compatible with all laser cut software, milling machine, CNC plasma cutting machine, glowforge machines.
This is an Instant Digital Download
The item is non-refundable because it's not physical.
YOU CAN use the files for personal purposes and for your small business.
YOU CANNOT share, redistribute or resell the files.
Copyright is not transferable with the sale.
