Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)
Sizes:
3 mm thickness: 174 x 65 x 74 mm (6,85 x 2,56 x 2,91'')
1/8''(3.175mm) thickness: 184 x 69 x 78 mm (7,25 x 2,71 x 3,08'')
4 mm thickness: 232 x 87 x 99 mm (9,13 x 3,41 x 3,88'')
6 mm thickness: 348 x 130 x 148 mm (13,70 x 5,12 x 5,83'')
1/4''(6.35mm) thickness: 368 x 138 x 157 mm (14,50 x 5,42 x 6,17'')
Work area:
3 mm thickness: 381 x 216 mm (15,00 x 8,50'')
1/8''(3.175mm) thickness: 403 x 229 mm (15,88 x 9,00'')
4 mm thickness: 508 x 288 mm (20,00 x 11,34'')
6 mm thickness: 762 x 432 mm (30,00 x 17,01'')
1/4''(6.35mm) thickness: 806 x 457 mm (31,75 x 18,00'')
In the file:
green color - draw (score - cut with little power and high speed)
blue color - engrave
pink color - cut (inner cut lines)
black color - cut (outer cut lines)
What you receive:
You will download 1 ZIP file containing the following:
the CDR, DXF, AI, SVG files with drawing for material thickness 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) and PDF-assembly instruction
If you have any questions feel free to contact us.
These files are vector-based and compatible with all laser cut software, milling machine, CNC plasma cutting machine, glowforge machines.
This is an Instant Digital Download
The item is non-refundable because it's not physical.
YOU CAN use the files for personal purposes and for your small business.
YOU CANNOT share, redistribute or resell the files.
Copyright is not transferable with the sale.
Wholesale cheaper
Use promocodes for discount
3 files - WHOLESALE3 - 15%
5 files - WHOLESALE5 - 20%
10 files - WHOLESALE10 - 30%
This model also available on Etsy here
